Hifi Tube Amplifier
DY-601
Home Theater System / Hifi Tube Amplifier
USD 39.9-399
Reference price range. Contact us to confirm your configuration, quantity and quotation.
Explore the product information below, or contact our team for availability and a quotation.
Request a quoteView original product informationProduct details
SPECIFICATIONS
- OUTPUT IMPEDANCE
- Speakers: 4Ω~8Ω
- Earphone: 32Ω~600Ω
- OUTPUT POWER: 5W x 2 at 1KHz
- Earphone: 600mW
- FREQUENCY RESPONSE: 10Hz-30KHz (-1dB)
- T.H.D: <1% (1W)
- S/N: >89dB
- INPUT IMPEDANCE: 50KΩ
- INPUT SENSITIVITY: 650mV
- VACUUM TUBES: 6N3 x 2, EL84 x 2
- POWER CONSUMPTION: 52W
- POWER REQUIREMENT
- Switchable: 110V/220/230V AC, 50~60Hz
- DIMENSIONS (L x W x H): 11.5" X 5.5" X 6" (238 mm x 138 mm x 148 mm)
- LINE IN TERMINAL: RCA stereo Connectors x 2
- SPEAKER TERMINAL: Binding posts x 2
- ACCESSORIES: Power cord x 1
- HEADPHONE JACK: Stereo (6.35 mm diameter)
- WEIGHT: Net Weight: 14.33 lbs. (6.5KG)
- Shipping Weight: 16.5 lbs. (7.5KG)
