PSVANE
274B-TII
39.9-399
Reference price range. Contact us to confirm your configuration, quantity and quotation.
Explore the product information below, or contact our team for availability and a quotation.
Request a quoteView original product informationProduct details
Filament Voltage:
Uf........................................................... 5 V
If........................................................... 2 A
Uf........................................................... 5 V
If........................................................... 2 A
Maximum Ratings:
Peak Anode Reverse Voltage................................... 1550 V
Peak Anode Current........................................... 750 mA
Peak Anode Reverse Voltage................................... 1550 V
Peak Anode Current........................................... 750 mA
Recommended Operating Conditions:
Anode Supply Voltage.......................................... 2×500 V
Impedance per Arm............................................ 75 Ω
Load Impedance................................................ 2000 Ω
Filter Capacitance............................................ 4 μF
Rectifier Current............................................. ≥220 mA
Anode Supply Voltage.......................................... 2×500 V
Impedance per Arm............................................ 75 Ω
Load Impedance................................................ 2000 Ω
Filter Capacitance............................................ 4 μF
Rectifier Current............................................. ≥220 mA
